238
TYPICAL LS SERIES HULL HARDWARE LS6 SHOWN
Plug; Garboard Drain - Black Marelon
Part No. 281278
Drill Hole: Ø 1 1/16"
Speaker
1
1
/
4
"
Transom Views
Speaker
21
10 1/2
Underwater Light
Drill Hole Size: Ø 5/8"
Fusion Stereo Remote
Speakers; Fusion 6" - MS- FR6020EM Bulk Pack
Part No. 957533
Swim Step Switch
Transom trim Switch
Stern Eye
Handle
16 1/2"
1 7/8
4 13/16
12 7/16
Tap Shower
Cold Only Angle Mount
Transom Shower
Part No. 282529
34 15/16
18 3/4
Transom Shower
18 7/16
Underwater Light
Drill Hole Size: Ø 5/8"
3/4" Drain Thru Hull
Garboard Drain
3 Step Ladder
Part No. 201629
5
1
/
2
"
Underside View of Transom
Handle
18 7/16
9 1/4
Underwater Light
Stern Eye
Speakers; Fusion 6" - MS- FR6020EM Bulk Pack
Part No. 957533
3/4" Thru Hull
Underwater Light
LS6 (MH) Hull Hardware
-
DATE:
3 OF 4
Spencer M.
2/12/2018
CVL
PROPRIETARY AND CONFIDENTIAL:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF REGAL MARINE
INDUSTRIES. ANY REPRODUCTION IN PART OR AS WHOLE WITHOUT THE WRITTEN
PERMISSION OF REGAL MARINE INDUSTRIES IS PROHIBITED.
REVISION:
DRAWN BY:
DRAWING TITLE:
APPROVED BY:
2300 JETPORT DRIVE
ORLANDO, FLORIDA 32809
TEL (407) 851-4360
REGAL MARINE INDUSTRIES
PAGE:
ALL RIGHTS RESERVED
DWG. NO.:
37
