TYPICAL DC (12 VOLT) WIRING COLOR CODE & SIZES (CONTINUED)
ORANGE 10,12
VACUUM TOILET,
REFRIGERATOR,
HATCH RAM
ORANGE 16 WIPER RUN
ORANGE/WHITE 16 WIPER PARK
ORANGE/BLACK 10,12,16 HORN, HATCH RAM
BLUE 14
INTERIOR LIGHTS, SWITCHED
CIRCUIT
BLUE/RED 14
INTERIOR LIGHTS, CONSTANT
HOT CIRCUIT
BLUE/BLACK 16 COCKPIT SOFT LIGHTS
BLUE/GREEN 16 INTERIOR SOFT LIGHTS
BLUE 10
CABIN LIGHT MAIN CIRCUIT
FEED
GRAY 14
NAVIGATION LIGHTS, RUN-
NING, BOW, TRANSOM
LIGHTS
GRAY/BLACK 14
NAVIGATION LIGHTS, AFT AN-
CHOR, MASTHEAD
GRAY/WHITE 14
NAVIGATION LIGHTS, MAST-
HEAD, FWD. RUNNING LIGHTS
RED 16
POSITIVE FEED- ELECTRON-
ICS, GAS VAPOR DETECTOR,
BREAKER TO DASH SWITCH
FEEDS
Note: The list above applies to a number of vessels. Vessel components/wiring may vary depending on the
model.
