TYPICAL DC (12 VOLT) WIRING COLOR CODE & SIZES (CONTINUED)
RED/WHITE 16 WINDLASS CONTROL-DOWN
RED/BLACK 16 WINDLASS CONTROL-UP
RED/WHITE 14 BATTERY PARALLEL-LOAD
RED 14 POSITIVE FEED-ELECTRONICS
RED 12 POSITIVE FEED-ELECTRONICS
RED 10 POSITIVE FEED-AUTO PILOT
RED/VIOLET 10
FUEL TANK TRANSFER PUMP
AMPLIFIER POWER
RED 8
POSITIVE FEED- MAIN
ALTERNATOR CHARGE
RED 6
POSITIVE FEED- MAIN
ALTERNATOR CHARGE
RED 4 POSITIVE FEED-MAIN
RED 2
POSITIVE FEED- MAIN STARTER,
BATTERY, GENERATOR
RED 2/0
POSITIVE FEED- MAIN, START-
ER, BATTERY
PURPLE 16
STBD. IGNITION, HOUR METER-
WINDSHIELD VENT
PURPLE/WHITE 16
PORT IGNITION, HOUR METER,
WINDSHIELD VENT
PINK 16 STBD. FUEL TANK SENDER
PINK/BLACK 16 PORT FUEL TANK SENDER
TAN/BLUE 16 ENGINE ALARM CIRCUIT
GREEN 16
TANK LEVEL MONITOR, SPOT-
LIGHT
GREEN 10 SPOTLIGHT
GREEN 8 BONDING
Note: The list above applies to a number of vessels. Vessel components/wiring may vary depending on the
model.
