I.
UNPACKING
Check to be sure the following items were
packed:
1 -
Transceiver
l-
MA-83 Hand Held Microphone (Blk)
1
-
~~-84
DC Power Cord w/5A in-line fuse
1
-
MA-311 Blk Mounting Bracket
II.
MAINTENANCE
Refer to a Regency Sales/Service Center for
servicing. The transceiver should be checked semi-
annually for proper operation.
WARNING:
FCC regulations require that any repairs
and/or adjustments made to the transmitter of this
radio to be rendered under the supervision of a
technician holding a general radiotelephone license.
DO NOT TAMPER WITH INTERNAL ADJUSTMENTS.
III.
DESCRIPTION
The RH256 and RU156 are sixteen-channel land
mobile transceivers.
The RH256 operates in the VHF
frequency range in three bands.
The RH256A operates
from 134 to 150 MHz; the RH256B operates from 150
to 162 MHz and the RH256C and RH256UK both operate
from 162 to 174 MHz.
The
RH256UK
is an
RH256C
but
instead of 25
KHzchannel
spacing and
+5
KHz maximum
system modulation deviation the radio is designed to
-l-
