DESCRIPTION (Continued)
MONITOR SWITCH
Placing this switch in the
"MON"
position
allows the user to monitor the channel when the
CTCSS decoder is operating.
NIGHT/DAY SWITCH
Placing this switch in the "DAY" position
places the display lights at maximum luminosity and
does not light the keyboard.
In the "NIGHT" position
the display light's luminosity is decreased and the
keyboard is illuminated.
STATUS LEDs
There are four status LEDs located to the left
of the channel display.
TX
-
When lit indicates that the transmitter is
SCAN
MSG
PRIOR
activated. This is accomplished by removing
the microphone from the hang-up clip
(off-
hook condition) and pressing the push-to-talk
switch on the microphone.
When lit indicates that the radio is in the
SCAN mode. Pressing the SCAN button on the
keyboard puts the radio in the SCAN mode.
When lit indicates that a message has been
received. The radio's CTCSS decoder must be
activated in order for this LED to function.
If a message has been received, going off hook
or changing the channel will reset the LED
to its OFF state.
When lit indicates that the radio's priority
function has been selected. Pressing the
Prior button on the keyboard will activate
and deactivate the PRIORITY function.
-4-
