2.3 Technical data
NEA Room Controller
NEA 230 V NEA 24 V
Colour
Front plate white (RAL 9016);
Back cover anthracite grey (RAL 7016)
Operating voltage 230 V, AC ±10 % 24 V, AC -10% / +20%
Max. switching current 0,2 A (resistive load) 1 A (resistive load)
Fuse T 0,63 A T 1 A
Safety Class II Class III
Max. number of actuators 5 thermal actuators
Degree of protection IP 30
Frost protection mode 5 °C
Dimensions, front 88 x 88 mm
Dimensions, rear 75 x 75 mm
Depth 26 mm
Storage temperature -20 – 60 °C
Ambient temperature 0 – 50 °C
Application In enclosed spaces
NEA Remote temperature probe
Sensor type NTC 10K (10 kOhm,1 % at 25 °C)
Cable length 4 m
Protection class IP 67
NEA Timer
Operating voltage 230 V AC
Number of memory locations 84
Power reserve 10 years
