Rehau nea Service Manual

SERVICE-MANUAL
NEA ROOM CONTROLLER 230V / 24V
© REHAU
10
Actuator
Actuator 230 V
Actuator 24 V
Operating voltage
230 V, AC +10%... -10%, 50/60 Hz
24 V, AC, +20% … - 10%, 0 - 60 Hz
Inrush current
300 mA for max. 200 ms
250 mA for max. 2 min
Operating power
1,8 W
Version
Normally closed (NC)
Closing and opening times
approx. 3 min
Actuator travel
4 mm
Actuator power
100 N ±5 %
Ambient temperature
0 …. 60°C
Degree / class of protection
IP 54/II
Housing
Polyamide / grey
Connecting cable
2 x 0,75 mm², 1 m
Dimensions W x H x D
44 mm x 58 mm x 47 mm

Rehau nea Specifications

General

Brand	Rehau
Model	nea
Category	Temperature Controller
Language	English
