4.2 Operation
The room control unit can be operated via the control knob:
Pressing the control knob activates menus and
functions.
+-
Rotation permits the target temperature to be set as
well as navigation between menus and their functions.
A basic level and three menus are available.
Basic level:
+-
Rotating adjusts the desired target temperature.
Menu selection with:
Functions: includes all important lifestyle functions.
Parameters: includes several parameters as e. g. heating and
setback temperatures, date and many more.
Service: includes settings for the specialist (secured by PIN,
see manual of the base station)
4.3 Commissioning (incl. pairing)
1. Activate the pairing function at the base station for the desired
heating zone (see manual base station Nea Smart 24 V).
2. Press the control knob for approx. 3 s. in order to activate pairing
function (the display shows "Set").
- The base station and the room control unit are connected to
each other.
- If the base station has been programmed before, the date and
time of the room control unit are set automatically.
For first commissioning of the base station:
Set year, date and time by rotating, confirm entries by pressing.
4.4 Connection test
Press the control knob for approx. 3 s. in order to activate pairing
function (the display shows "Set").
At the base station, the heating zone connected to this room control
unit is changed for 1 minute, in other words switched on or o
depending on the previous operating status.
4.5 Comfort programs - Smart Start/Stop mode
Comfort programs include pre-defined heating times to be used for
working days (1-5) or for the weekend (6-7). Outside the heating
times the installation switches to night mode. You can select the
comfort programs in the Parameter menu. The Smart Start/Stop Mode
of the system calculates the required delay times to reach the
desired temperature at the starting and finishing time of the heating
program.
Program Comfort time 1 Comfort time 2
P0 05:30 – 21:00 –
P1 04:30 – 08:30 17:30 – 21:30
P2 06:30 – 10:00 18:00 – 22:00
P3 07:30 – 17:30 –
Tab. 4-2 Predefined time programs
You can create individual comfort programs with the on-line software
available under www.ezr-home.de and transfer these to the basis
station with a MicroSD card.
4.6 Lifestyle functions overview
In this menu you can activate or deactivate the lifestyle functions.
1. Press the control knob.
2. Activate the menu “Lifestyle functions” by pressing the control
knob again.
3. Select the desired lifestyle function.
The following lifestyle functions are available to you; you can find
further information in the table “Functions” on the next page.
It may take up to 10 minutes before changes of global lifestyle
functions are displayed on all room control units.
+
–
Fig. 4-2 Selection menu of lifestyle-functions
8
