7
Free Spool Operation
To be able to operate the Free spool clutch handle
there must be no load on the drum.
Loosen the butterfly screw and remove the handle Rotate and insert the handle as shown into the free
spool mechanism and anchor point.
Pull the handle as shown to activate the freespool
mechanism and unspool as much cable as required.
1 2 3
Note: The mechanism will only be active as
long as the lever is held in the active position
