REISHAUER RZ 150 - Scale X-Axis; Workpiece Spindle; Monitoring Workpiece Center Sleeve

RZ 150
Options, Interfaces
Reishauer List of Options RZ 150
V09
Elektronik Kurs
239
Scale X-axis
Option datum:
MD14510[117]
PLC-address:
DB20.DBW234
Data type:
Integer
Description:
Defines if a X-axis scale is attached or not.
Schematic block 4300
Valid as of:
PLC V1.050

Value
Function
Description, Remark
0
Scale X-axis not available.
1
Scale X-axis available and active.
Workpiece Spindle
Option datum:
MD14510[111]
PLC-address:
DB20.DBW222
Data type:
Integer
Description:
Defines which workpiece spindles are attached.
Schematic block 5200
Valid as of:
PLC V1.050

Value
Function
Description, Remark
0
No workpiece spindle available.
1
C1-axis available
2
C2-axis available
3
C1- and C2-axis available.
Monitoring Workpiece Center Sleeve
Option datum:
MD14510[135]
PLC-address:
DB20.DBW270
Data type:
Integer
Description:
Defines if a sensor for monitoring the workpiece center sleeve is installed.
The sensor will detect the lifting of the workpiece center sleeve.
Schematic block 5200
Valid as of:
PLC V1.088

Value
Function
Description, Remark
0
Monitoring workpiece center sleeve inactive.
1
Monitoring workpiece center sleeve active.
