Ghost BACKUP / RESTORE with PCU50.3
3. In the Siemens HMI under SERVICES ->/ > ->/ SERIES START-UP:
Configure PLC-archive.
File name with following format: PLYYMMDD (YearMonthDay)
Example: PL060723P
4. Under START-UP -> MACHINE DATA:
Configure TEA- files
(Axis- and drive MD’s for all axes incl. general MD’s and channel MD’s).
File name:
General MD’s ALLG_MD
Channel 1, Channel 2 MD’s: CHAN1, CHAN2
Axis-MD’s AX_X, AX_Y, AX_Z, ...., AX_B.
Drive-MD’s: VSA_X, VSA_Y, VSA_Z, ...., VSA_B.
Load NC-programs:
In HMI under service, press the SOFTKEY Load NC programs.
Clean-up Hard Disk
Delete all old archives (Siemens HMI, services), delete in Explorer all files
and archives in disk drive D:\ , except the following archives.
DO NOT delete the following archives
Ac-Log, Eboot, Gtmp, Images, Install, Software, Rimages, Setups, Tmp
and Updates
Empty waste basket.
Prepare memory medium for data transfer
A USB stick or an external harddisk with USB connection can be used.
On the memory stick or the HD approx. 2 GB of free capacity should still be avail-
able.
Configure a directory with the name of the machine number, LW:\7Xnnn.
Configure Ghost Image
Send Ghost Image from machine to data carrier.
Is valid starting aprox. beginning of 2006.
Start Siemens Service Center
For the PCU50.3 there is no longer a DOS-service menu available, this has been
replaced by the Service Center.
This is based on WindowsPE, a Windows version, which can be started from a CD
or another data medium (also from not writeable data medium).
The Service Center can be handled like a normal Windows pogram with the
mouse.
Attach data carrier (USB stick min. 4GB or an external HD with USB connec-
tion) to the USB port.
Start PCU in service mode and start Service-Center (link on desktop).
