Doc ID: 193-300A
Revision: 121718
9
Normal - Ramps with machine marks or look
shiny/polished are normal. These can be reused.
Damaged - Ramps that have a raised outline (burr)
or have an indentation are damaged and need to be
replaced.
Raised mark (burr) Indentation
NOTE: If you replace the EXP bases, it is HIGHLY
RECOMMENDED that you replace the Teflon pads or
wedges as well for best performance.
To Next Page
