REL Acoustics QUAKE - Specifications (Continued)

REL Acoustics ‘Q’ range User manual
24
SPECIFICATIONS (Cont.)
MODEL Q200E/Q201E Q400E (Q401E USA)
Type
Closed box working below system resonance using the unique REL
Zero-Q loading system
Enclosure volume Litres 17 25
Drive unit 250 mm extra long throw , cast
chassis
300 mm extra long throw, cast
chassis
Lower frequency response in
room at –6dB
17Hz 14Hz
Input connectors
Hi Level Neutrik Speakon
Lo Level twin phonos 0dB and
+12dB
Hi Level Neutrik Speakon
Lo Level twin phonos 0dB and
+12dB
Input impedance Ohms
Hi Level 100k
Lo Level 0dB 10k
Lo Level +12db 2.5k
Hi Level 100k
Lo Level 0dB 10k
Lo Level +12db 2.5k
Gain control range 56dB 80dB
Power output (RMS) Watts 200 400
Mode selector Yes, see page 12 Yes, see page 12
Phasing Positive or reversed, page 13 Positive or reversed, page 13
Amplifier type DC coupled mosfet DC coupled mosfet
Protection System
1. Fully electronic with SET-SAFE
Yes Yes
2. D.C. Fault Yes Yes
3. Output short Yes Yes
Mains input voltage
220-240 volts, 110-120 volts for
certain markets
220-240 volts, 110-120 volts for
certain markets
Fuses
2 Amp semi delay 230 volts
operation
3.15 Amp semi delay 110 volts
operation
5 Amp semi delay 230 volts
operation
8 Amp semi delay 110 volts
operation
There Are No Internal User Replaceable Parts
Dimensions mm Inc feet and rear
panel controls
Dimensions inches Inc feet and
rear panel controls
Q201E – 300 x 328 x 353
Q200E – 300 x 303 x 323
Q201E – 11.81 x 12.91 x 13.9
Q200E – 11.81 x 11.93 x 12.72
392 x 420 x 430
15.43 x 16.54 x 16.93
Net weight Kg (lbs.) Q201E – 17 (37.48)
Q200E – 16.22 (35.68)
30 (66.14)
Supplied Accessories
Mains lead Yes Yes
Neutrik Speakon Interconnect
10 Metres nominal
Yes Yes
5 metre phono interconnect Yes Yes
Users manual Yes Yes
Spikes Yes Yes
Nylon Screws Yes Yes
Nylon Feet Q201E – Yes, Q200E - No No
Grille Q201E – Yes, Q200E - No Yes
In the interest of product development, REL Acoustics Limited reserve the right to vary these
specifications without notice
