Technical Data
Reliable Single Interlock Preaction Systems, with associated
trim, size 2” (50 mm), 2½” (65 mm), 76 mm, 3” (80 mm), 4”
(100 mm), 165 mm, 6” (150 mm) & 8” (200 mm) are rated
for use at minimum water supply pressure of 20 psi (1.4 bar)
and maximum supply pressure of 250 psi (17.2 bar) for 2”
(50mm), 2½” (65mm), 76mm, 3” (80mm) and 8” (200mm)
valve sizes and 300 psi (20.7 bar) for 4” (100mm), 165mm and
6” (150mm) valve sizes. Water supplied to the inlet of the valve
and to the pushrod chamber must be maintained between 40°F
(4°C) and 140°F (60°C).
The following list of technical bulletins pertains to valves and
devices that may be used in this preaction system:
Deluge Valve Reliable 519
Hydraulic Emergency Station (Model A) Reliable 506
Mechanical Sprinkler Alarm Reliable 612/613
Pressure Maintenance Device Reliable 251
Nitrogen Regulating Device Reliable 254
Air Compressor Panel
(Models B-SI & C-SI)
Reliable 252
Releasing/Control Panel Potter 5403550
Pilot Line Detector Reliable 180
Waterflow Pressure Alarm Switch Potter 5400928
Model DDX Deluge Valve Description
1. Rated working pressure:
Valve & System - 250 psi (17.2 bar) for 2” (50mm), 2
1
/
2
”
(65mm), 76mm, 3” (80mm) and 8” (200mm) valve siz-
es and 300 psi (20.7 bar) for 4” (100mm), 165mm and
6” (150mm) valve sizes.
2. Factory tested to a hydrostatic pressure of 500 psi (34.5
bar) for 2” (50mm), 2½” (65mm), 76mm, 3” (80mm) and 8”
(200mm) valve sizes and 600 psi (41.4 bar) for 4” (100mm),
165mm and 6” (150mm) valve sizes. (Valve only)
3. End and trim connections:
• ANSI/AWWA C606 grooved inlet and outlet
Nominal Pipe
Size
Outlet
Diameter
Groove
Diameter
Groove
Width
Outlet
Face to
Groove
2” (50 mm)
2.375”
(60mm)
2.250”
(57mm)
11/32”
(9.0mm)
5/8”
(16mm)
2½” (65 mm)
2.875”
(73mm)
2.720”
(69mm)
11/32”
(9.0mm)
5/8”
(16mm)
76 mm
3.000”
(76mm)
2.845”
(72mm)
11/32”
(9.0mm)
5/8”
(16mm)
3” (80 mm)
3.500”
(89mm)
3.344”
(85mm)
11/32”
(9.0mm)
5/8”
(16mm)
4” (100 mm)
4.500”
(114mm)
4.334”
(110mm)
3/8”
(9.5mm)
5/8”
(16mm)
165 mm
6.500”
(165mm)
6.330”
(161mm)
3/8”
(9.5mm)
5/8”
(16mm)
6” (150 mm)
6.625”
(168mm)
6.455”
(164mm)
3/8”
(9.5mm)
5/8”
(16mm)
8” (200 mm)
8.625”
(219mm)
8.441”
(214mm)
7/16”
(11mm)
3/4”
(19mm)
• Threaded openings Per ANSI B 2.1
• Flange Dimensions
Flange
Type:
Nominal
Pipe
Size
Bolt
Circle
Diameter
Bolt
Hole
Diameter
Flange
Outside
Diameter
Flange
Thick-
ness
Number
of
Bolts
ASME B16.5
Class 150
4”
(100mm)
7½”
(191mm)
¾”
(19mm)
9”
(229mm)
15
/
16
”
(24mm)
8
ISO 7005-2
PN16
4”
(100mm)
7
3
/
32
”
(180mm)
¾”
(19mm)
9”
(229mm)
15
/
16
”
(24mm)
8
ASME B16.5
Class 150
6”
(150mm)
9½”
(241mm)
7
/
8
”
(22mm)
11”
(279mm)
15
/
16
”
(24mm)
8
ISO 7005-2
PN16
6”
(150mm)
9
7
/
16
”
(240mm)
29
/
32
”
(23mm)
11”
(279mm)
15
/
16
”
(24mm)
8
ASME B16.5
Class 150
8”
(200mm)
11¾”
(298mm)
7
/
8
”
(22mm)
13½”
(343mm)
1”
(25.4mm)
8
ISO 7005-2
PN16
8”
(200mm)
11
5
/
8
”
(295mm)
29
/
32
”
(23mm)
13½”
(343mm)
1”
(25.4mm)
12
4. Valve Exterior’s Color:
Valve Size Color
2” (50 mm) Black or Red
2½” (65 mm) Black or Red
76 mm Red
3” (80 mm) Black or Red
4” (100 mm) Black or Red
165 mm Red
6” (150 mm) Black or Red
8” (200 mm) Black or Red
5. Face to face dimensions:
Valve Size:
End
Connection:
End to End:
2" (50mm), 2½" (65mm),
76mm & 3" (80mm)
Groove/ Groove 12½" (318mm)
4" (100mm)
Groove/ Groove 14" (356mm)
Flange/ Groove 16" (406mm)
Flange/ Flange 16" (406mm)
6" (150mm) & 165mm
Groove/ Groove 16" (406mm)
Flange/ Groove 19" (483mm)
Flange/ Flange 19" (483mm)
8" (200mm)
Groove/ Groove 19
3
/
8
” (492mm)
Flange/ Flange 21¼" (540mm)
6. Valve Shipping Weight:
Valve Size: End Connection: Weight:
2" (50mm), 2½" (65mm),
76mm & 3" (80mm)
Groove/ Groove 34 lbs (15 kg)
4" (100mm)
Groove/ Groove 64 lbs (29 kg
Flange/ Groove 79 lbs (36 kg)
Flange/ Flange 92 lbs (42 kg)
6" (150mm) & 165mm
Groove/ Groove 95 lbs (43 kg)
Flange/ Groove 122 lbs (56 kg)
Flange/ Flange 138 lbs (69 kg)
8" (200mm)
Groove/ Groove 148 lbs (67 kg)
Flange/ Flange 197 lbs (90 kg)
7. Trim Shipping Weight:
Trim
Conguration
2" (50 mm),
2½" (65 mm),
3" (80 mm)
& 76 mm
4" (100 mm),
6" (150 mm),
8" (200 mm)
& 165 mm
Wet Pilot Single Interlock 32 lbs (15 kg) 38 lbs (17 kg)
Dry Pilot Single Interlock 45 lbs (20 kg) 52 lbs (24 kg)
Electric Actuation Single Interlock 35 lbs (16 kg) 40 lbs (18 kg)
