Reliable DDX - Deluge Valve Parts List (Screw-In Seat); Model DDX Parts Breakdown

18.
Model DDX (Screw-In Seat Conguration) Deluge Valves Parts List
Item
No.
Part No.
Part Description QT Y. Material
2"
(50mm)
2½"
(65mm)
76mm
3"
(80mm)
4”
(100mm)
165mm
6”
(150mm)
8"
(200mm)
1
91006011 91006012 91006023 91006013 91006005 91006027 91006007 91006028 Valve Body Groove/Groove
1 Ductile Iron 65-45-12
N/A N/A N/A N/A 91006045 N/A 91006067 N/A Valve Body Flange/Groove
N/A N/A N/A N/A 91006035 N/A 91006037 91006039 Valve Body Flange/Flange
2 N/A N/A N/A N/A N/A N/A 95406414 O-ring (Mounting Ring) 1 Buna-N
3 71040416 Pushrod Cover Assembly 1
Ductile Iron 65-45-12
& Brass C360000
4
91106123 N/A N/A N/A Hex Bolt ½”-13 x 1¼” 6
Zinc Plated Steel
N/A 95606107 N/A N/A Hex Bolt ½”-13 x 1½” 6
N/A N/A 91106006 N/A Hex Bolt
5
/
8
”-11 x 1¾” 6
N/A N/A N/A 95606110 Hex Bolt
5
/
8
”-11 x 2” 8
5 91306013 91306014 91306016 91306018 Mounting Ring 1 Stainless Steel CF8 or CF8M
6 91916003 91916014 91916016 91916008 Clapper 1 Stainless Steel CF8 or CF8M
7 92116063 92116064 92116065 92116066 92116068 Access Cover 1 Ductile Iron 65-45-12
8 93416003 93416014 93416016 93416008 Seal Assembly 1 Stainless Steel 304 & EPDM
9 93706003 93706004 93706006 93706008 Access Cover Gasket 1 Buna-N or Neoprene
10
93722000 93722000 N/A N/A
Bumpstop Assembly
1
Stainless Steel UNS S31600
& EPDM
N/A N/A 93722000 N/A 2
N/A N/A N/A 93722000 3
11 93916006 Pushrod Guide 1 Acetal
12 93916066 Reset Shaft 1 Brass UNS C36000
13 94106066 Reset Housing 1 Brass UNS C36000
14 94356006 Reset Knob 1 Aluminum 6061
15 94506003 94506004 94506016 94506008 Lever 1 Stainless Steel UNS S17400
16 95006414 94006412 95006410 95006410 Striker 1 Aluminum Bronze C95400
17 95106006 Piston 1 Stainless Steel CF8M
18 95276006 Diaphragm 1 EPDM & Polyester
19
95306267 N/A N/A N/A
Retaining Ring,
3
/
8
" Shaft,
Lever Pin
2 Stainless Steel 15-7 or 17-7
N/A 95306267 N/A N/A
Retaining Ring, ½ ” Shaft, Lever
Pin
N/A N/A 95306269 N/A
Retaining Ring,
5
/
8
” Shaft, Lever
Pin
N/A N/A N/A 95316408
Retaining Ring, ¾ ” Shaft, Lever
Pin
20
95306268 N/A N/A N/A
Retaining Ring,
3
/
8
” Shaft,
Hinge Pin
2 Stainless Steel 15-7 or 17-7N/A 95306267 95306267 N/A
Retaining Ring, ½ ” Shaft, Hinge
Pin
N/A N/A N/A 95316408
Retaining Ring,
3
/
4
” Shaft, Hinge
Pin
21 95406007 O-Ring, Reset Housing ID 1 Buna-N
22 95406024
O-Ring, Reset Housing &
Pushrod Guide OD
2 Buna-N
23 95406407 O-Ring, Pushrod Guide ID 1 Buna-N
24 95406410 95406409 95436126 95406413 O-Ring, Upper Seat 1 Buna-N
25 95406411 95406420 95446226 95406412 O-Ring, Lower Seat 1 Buna-N
26 95506006 Pushrod 1 Stainless Steel UNS S30300
27 95606114
Socket Head Screw, ¼”-20
x
5
/
8
”
6 Steel
28 95606127
Flat Head Socket Cap Screw
3
/
8
"-16 x ¾"
1 Steel
29
95606133 N/A N/A N/A
Socket Head Screw #6-32
x ½"
1
Stainless Steel 18-8
N/A 95606130 95606130 95606130
Socket Head Screw #10-32
x 1"
Stainless Steel UNS S31600
30 96016003 96016014 96016016 96016008 Seat 1 Stainless Steel CF8M
31
96206003 N/A N/A N/A
Hinge Pin 1
Stainless Steel UNS S30400
N/A 96216086 96216086 96206008 Stainless Steel UNS S21800
32
96216003 N/A N/A N/A
Lever Pin 1
Stainless Steel UNS S17400
N/A 96216044 96216047 96216008 Stainless Steel UNS S21800
33 96310003 96906904 96906904 96310008 Clapper Spacer 2 Teflon or Acetal
