Instruction Manual
MD65 EtherNet/IP
Communications Module
M/N MDCOMM-ENET
D2-3529

Table of Contents

Questions and Answers

  • M
    mullinsbernardAug 19, 2025
    What to do if the DRIVE Status Indicator is flashing red on my Reliance Electric Control Unit?
    • C
      Cathy SkinnerAug 19, 2025
      If the Reliance Electric Control Unit's DRIVE Status Indicator is flashing red, it could be due to a communication issue. In Single mode, the module might not be receiving communication from the drive. In Multi-Drive mode, it might not be receiving communication, or the drive might not be a Reliance Electric drive. Here are some troubleshooting steps: * Verify the setting for parameter 22 (MDI I/O Cfg). * Ensure cables are securely connected and undamaged; replace if necessary. * Try cycling power to the drive. * Make sure you are using Reliance Electric MD65 and MD 60 AC Drives.
  • D
    Denise GarrisonAug 22, 2025
    Why is the NET A Status Indicator flashing green on my Reliance electric MD65?
    • T
      Toni ClarkAug 22, 2025
      If the NET A Status Indicator is flashing green on your Reliance Electric Control Unit, it means the module is properly connected but not communicating with devices on the network. To resolve this: * Place the controller in RUN mode. * Program a controller or peer device to recognize and transmit I/O or establish a messaging connection to the module. * Configure the module for the program in the controller.
  • N
    nandersenAug 25, 2025
    What does it mean if the NET A Status Indicator is flashing red on a Reliance electric MD65 Control Unit?
    • G
      gabrielaleeAug 25, 2025
      If the NET A Status Indicator on your Reliance Electric Control Unit is flashing red, it indicates that an EtherNet/IP connection has timed out. To resolve this: * Ensure the scanner is in RUN mode. * Check the network traffic to see if there is too much traffic.
  • T
    tjonesAug 26, 2025
    Why is the DRIVE Status Indicator solid red on my Reliance Electric Control Unit?
    • J
      Joan OrtegaAug 26, 2025
      If the DRIVE Status Indicator on your Reliance Electric Control Unit is solid red, it means the drive has refused an I/O connection from the module, or another MDI peripheral is using the same MDI port. Cycle power to the product after checking that all MDI cables are securely connected and not damaged. Replace cables if necessary.
  • A
    Alejandro RodriguezAug 28, 2025
    What does it mean if the MS Status Indicator is flashing green on a Reliance Electric Control Unit?
    • T
      Tara WilliamsAug 28, 2025
      If the MS Status Indicator on your Reliance Electric Control Unit is flashing green, it indicates that the module is operational but is not transferring I/O data. To resolve this: * Place the scanner in RUN mode. * Program the controller to recognize and transmit I/O to the module. * Configure the module for the program in the controller.
  • X
    xhardyAug 30, 2025
    Why is the NET B Status Indicator off on my Reliance electric MD65?
    • C
      Colin MorrisonAug 30, 2025
      If the NET B Status Indicator on your Reliance Electric Control Unit is off, it indicates the module is not powered or transmitting on the EtherNet/IP network. First, if Net A is off: * Securely connect the module to the drive using the Internal Interface cable and to the network using an Ethernet cable. * Ensure the Ethernet cable is correctly connected to the Ethernet connector. * Set a unique IP address using a BOOTP server or by disabling BOOTP and using parameters. If Net A is solid Red: * Configure the module to use a unique IP address and cycle power. If Net A is flashing red: * Check the IP address in the module and scanner. * Ping the module. Note: This is normal if the module is idle.
  • N
    Nichole ReyesSep 1, 2025
    What should I do if the MS Status Indicator is flashing red on my Reliance Electric Control Unit?
    • C
      Cheyenne GloverSep 1, 2025
      If the MS Status Indicator on your Reliance Electric Control Unit is flashing red, it means that the module has failed the firmware test. To resolve this: * Cycle power to the drive. * If cycling power does not correct the problem, the parameter settings may have been corrupted. Reset defaults and reconfigure the module. * If resetting defaults does not correct the problem, flash the module with the latest firmware release.
  • G
    griffithtimothySep 3, 2025
    How to fix a Reliance electric MD65 when the DRIVE Status Indicator is off?
    • T
      terrance55Sep 3, 2025
      If the DRIVE Status Indicator is off on your Reliance Electric Control Unit, it indicates that the module is not powered or not properly connected to the drive. To resolve this: * Securely connect the module to the drive using the Internal Interface (ribbon) cable. * Apply power to the drive.
  • M
    Mr. Thomas Huber Jr.Sep 6, 2025
    Why is the NET A Status Indicator off on my Reliance electric MD65 Control Unit?
    • M
      Mallory WhiteSep 6, 2025
      If the NET A Status Indicator on your Reliance Electric Control Unit is off, this could be due to several reasons: the module and/or network is not powered, the module is not properly connected to the network, or the module needs an IP address. To resolve this: * Securely connect the module to the drive using the Internal Interface (ribbon) cable and to the network using an Ethernet cable. * Correctly connect the Ethernet cable to the Ethernet connector. * Set a unique IP address using a BOOTP server or disabling BOOTP and using parameters. * Apply power to the drive and network.
  • K
    Kent HarperSep 8, 2025
    What to do if the MS Status Indicator is solid red on a Reliance Electric Control Unit?
    • C
      Crystal BautistaSep 8, 2025
      If the MS Status Indicator on your Reliance Electric Control Unit is solid red, it indicates that the module has failed the hardware test. You can try the following: * Cycle power to the drive. * If the issue persists, replace the module.
