REMET CNC RT-630 - Device Specifications

REMET CNC TECHNOLOGY SP. Z O.O.
Page 5 z 22
Manufacturer of machinery and equipment, CNC machining service
3. DEVICE SPECIFICATION
Technical specifications:
Typ RT-630
MINIMUM / RECOMMENDED POWER
* [HP]
25/50*
RECOMMENDED ROTATION PTO
SHAFT (RIGHT SIDE) [rpm]
750-1000
CUTTER DIAMETER [mm] 620
NUMBER OF KNIVES 4 + 1 przeciw ostrze
Material of CUTTING KNIVES Stal HARDOX typ 500
Recommended overload clutch [Nm]
**
900-1700
LOAD FEEDER [mm] 480x480
FIXING SYSTEM three-point system
Max. cutting diameter of fresh soft
wood [mm] *
120
Max. cutting diameter of fresh hard
wood [mm] *
100
Max. cutting diameter of dry hard
wood [mm] *
80
CHIPER DIMENSIONS WITH FOLDED
CHARGE FUNCTION L x W x H
85 / 85 / 150
PIVOTING ANGLE OF THE EQUIP-
MENT PIPE
360˚
HEIGHT OF EXTRUSING PIPE [cm] 160
Weight [kg] 200
* The maximum diameter of shredded branches depends on the type of wood and
the conditions when cutting the material. For hardwood (e.g. oak / beech), the
maximum cutting diameter will be smaller than softwood (e.g. pine, spruce). For
dry or knotty wood, the maximum cutting diameter will also be reduced.
** Clutch selection parameter should be corrected with max. the PTO torque on
the tractor
