Remos GX - Page 21

Rev. 02 – July 16
th
, 2009
2 Airplane and Systems Descriptions
Airplane and Systems Descriptions 2 - 11
Configuration A
(“Explorer”/“Aviator I”-package with GPS option)
This avionics package contains a
Garmin SL-40 radio (optional
NAV/Comm Garmin SL-30), a
Garmin transponder (mode-C
transponder GTX-327 or mode-S
transponder GTX-328 or GTX-
330), along with the audio-panel
Garmin GMA-240. An audio input
allows connection of external
audio devices.
Optional a Garmin GPS
296/495/496, mounted into an
AirGizmo dock, can be installed
as illustrated
Configuration B
(“Aviator II”-package)
This package consists of a
Garmin SL-40 radio, a
NAV/COMM Garmin SL-30, a
Garmin transponder (mode-C
transponder GTX-327 or mode-S
transponder GTX-328 or GTX-
330), along with the audio-panel
(with marker beacon) Garmin
GMA-340. An audio input allows
connection of external audio
devices. A Garmin GPS 496,
mounted into an AirGizmo dock, is
installed as illustrated.
