CHILD SAFETY (continued)
Fitting a child seat
• Read the instructions carefully
before fitting and using the seat;
• attach fitting guides 2 to rings 1
fitted to the vehicle rear seats;
Fitting a child seat (continued)
• slide seat catches 3 into guides 2
and push the seat hard to lock it
on the rings;
• check that the seat is locked
correctly by moving it from left to
right and then forwards and
backwards.
A front-facing Isofix seat fitted on
the rear side seat
When a front-facing child seat is
installed, the front seat must not be
moved back beyond the halfway
point on the seat runners and the
seatback must not be reclined too
far.
Each of the rear seats is fitted with
two rings for mounting the base of
the sea t.
