5.19
FUSES
CORRECT INCORRECT
Fuse box 2
If an electrical component fails to
operate, check that the fuses are
sound before making further
investigations.
Raise cover A using handle 1.
To identify the fuses, refer to label 4
(shown on the following page).
It is advisable not to use the free
fuse locations.
Check the fuse in question
and replace it, if necessary,
with a fuse of the same
rating.
If a fuse is fitted where the rating is
too high, it may cause the electrical
circuit to overheat (risk of fire) in
the event of an item of
equipment using an excessive
amount of current.
Use the tweezers 3 to remove the
fuse.
To remove the fuse from the
tweezers, slide the fuse to the side.
A sensible precaution:
obtain a box of spare bulbs and
fuses from your RENAULT
Dealer.
