3.17
REAR SEAT (operation)
The seat and the seatback may be
folded away to allow bulky objects
to be carried.
To fold away the seat
Raise the seat cushion A against the
front seats
To fold down the seatback
Remove the rear head restraints (if
fitted). Press button 2 and lower
seatback B.
Remove the seat squab
Raise the seat squab to remove the
brackets 3 from their housing 4.
To replace the seat cushion,
proceed in the reverse order of
removal. Ensure that the seat squab
is supported correctly.
• When refitting the seatback, make sure that the the upper section is locked in place correctly. Where seat
covers are fitted, make sure these do not prevent the seatback latch from locking in.
• When moving the bench seat,makesuretheseatbeltreels1 are correctly repositioned before folding down
the seat, cushion.
When the bench seat has been put back in place, make sure the seat belt reels are correctly repositioned.
