Fusibles GPL X52 (BBA - Renault)
1 Empty location
2
Left-hand main beam
headlight
3
Right-hand main beam
headlight
4
Left-hand dipped beam
headlight
5
Right-hand dipped beam
headlight
6 Left-hand side light
7
Cluster /Radio/ Ultra low
cost/Amplifier
8
First Row Accessory
Socket
9 Blower Motor
10 Fuel Pump Fuse
11
Instrument panel-
Automatic transmission
12 Roof Light
13 Cluster
14 Low Beam
15
Radio/Ultra low cost/
Amplifier/Diagnostic
Socket, Roof Light
16 Empty location
17 Cluster
18 Lighting Switch
19 Electrical Door Locking
20 Electrical Door Locking
21 Electrical Door Locking
Empty Location
24
Cluster,Fuel pump Relay,
Injection Engine Control
Unit/Starter
25
Stop Light Switch, Radio/
Ultra Low cost
26 Rear Light Switch
27 Windshield Motor
28 Front Dual Window Lift
29 Power Steering
30 Air-Bag
31 Transponder Ring
32 to 35 Empty Location
36
Instrument panel/Starter-
Manual transmission
37 to 39 Empty Location
