Heating and air conditioning system
Manual air conditioning
All the controls for the air conditioning system are
located between the air vents.
If you want to:
– activate the air conditioning: press switch 1 ;
– choose the temperature : move lever 2 ;
– modify the distribution of air : scroll through the
6 positions by pressing switch 3 ;
– adjust the ventilation speed: press switch 4;
– activate the air recirculation : press switch 5.
Automatic climate
control
To benefit from automatic climate control, choose
the right and left-hand temperatures required using
levers 7 and 8 and select one of the three auto-
matic programs:
– AUTO :
mode where the temperature is reached
gradually ;
– SOFT : mode where the temperature is reached
slowly ;
– FAST : mode where the temperature is reached
quickly.
Note: pressing one of the other buttons will exit
automatic mode according to your requirements.
H E A T I N G A N D A I R C O N D I T I O N I N G S Y S T E M
5
1
2
3
4
7
8
AIR CONDITIONING
Button
6:
– authorises the air conditioning (AC OFF indica-
tor light off); in this case, the system decides
whether air conditioning is needed.
– prohibits the air conditioning (AC OFF indicator
light on); in this case, the air conditioning is de-
activated.
AUTOMATIC RECIRCULATION
Your automatic climate control is fitted with a
sensor that measures the external air quality. If
polluted air is detected, air recirculation will be ac-
tivated automatically.
Note : the integrated indicator on button 5 only
comes on when air recirculation is activated manu-
ally.
6
