CHILD SAFETY (continued)
Fitting a child seat
(continued)
• Remove padded section 1 held in
place by hook-and-loop fastener.
• Hold the seat in position so that
the catches on the seat are
opposite the two rings 2 fitted to
the rear side seat of the vehicle.
• Latch the hooks onto the rings
and make sure it is locked in
place properly by moving it
forwards and backwards and from
right to left.
• Push firmly on the base of the seat
to bring it into contact with the
seatback and make sure it is
securely in position.
In rear-facing position: use the
strap 3 supplied with the seat. Fix
hook 4 on handle 5.
If the seat is equipped
with two handles, be
sure to take the smaller
of the two (lower
fixed-positon handle).
