1.52
INSTRUMENT PANEL: displays and indicators
Rev counter 1
(graduations × 1000)
The red numbers indicate forbidden
engine speeds.
Speedometer 2
In kilometres or miles per hour.
Overspeed buzzer
Depending on the vehicle, a
buzzer sounds for approximately
10 seconds every 40 seconds, as
long as the vehicle is travelling in
excess of 75 mph (120 km/h).
Instrument panel in miles:
it is possible to switch to km/h.
- with the ignition off, press button
3 or 4 and starter button 5.
- the speed measurement unit
indicator flashes for
approximately three seconds, then
the new unit is displayed: release
button 3 or 5.
To return to the previous mode,
carry out the same operation.
Note: once the battery is switched
off, the trip computer automatically
returns to the original unit.
