INSTRUMENT PANEL: displays and indicators (continued)
Coolant temperature indicator 6
In normal use, the level must be
below zone 6a.Undersevere
conditions the needle may
approach this zone. But the
situation is not serious
unless the warning light
lights up, accompanied by a
message on the instrument panel, a
beep and warning light 6a.
Fuel level gauge 7
The number of lit squares shows the
remaining fuel level.
When it is at minimum, the bottom
square lights up and flashes. Then a
beep will be heard: refill as soon as
possible.
Information display 8
Depending on the vehicle, it
includes:
- the time,
- the external temperature,
- radio signals,
- navigation aid information.
