Renegade COMMANDO - Instrument Panel

1
INSTRUMENT PANEL
2
3
5
4
6
1
2
3
4
5
7
8
9
6
1
7
RENEGADE SPORTS S
RENEGADE COMMANDO
UM RENEGADE
COMMANDO & SPORTS S
19
1. High Beam Indicator : It will turn on when the
head light is in high beam position.
2. System Auto Maintenance : Automated alert
indicator for service maintenance.
3. Battery Charging : It will turn on when battery
voltage is low.
4. Odometer : Indicates accumulated distance.
5. Fuel gauge : Indicates fuel level on.
6. System Auto Maintenance : Automated
alert indicator for service maintenance.
7. Neutral light : Indicates when engine is in
neutral and there is no gear engaged.
8. Side Indicator : It will turn on when side
indicator lamp on
9. Overheating Sensor : It will glow when engine
temperature is high.
