Renesas RL78/G1D Application Note

RL78/G13 Handshake-based SPI Master Transmission/Reception
R01AN6883EJ0100 Rev.1.00 Page 19 of 38
June.15.23
[Function Name] R_TAU0_Channel3_Higher8bits_Start
Synopsis
TAU0 channel 3 upper 8 bits start operating
Header
r_cg_macrodriver.h
r_cg_timer.h
r_cg_userdefine.h
Declaration
void R_TAU0_Channel3_Higher8bits_Start (void)
Explanation
Starts operation of the upper 8 bits of TAU0 channel 3.
Arguments
• None
Return value
• None
Remarks
None
[Function Name] R_CSI00_Start
Synopsis
CSI00 start operating
Header
r_cg_macrodriver.h
r_cg_serial.h
r_cg_userdefine.h
Declaration
void R_CSI00_Start (void)
Explanation
Starts the operation of CSI00.
Arguments
• None
Return value
• None
Remarks
None
[Function Name] CSI00_Status_check
Synopsis
CSI status check
Header
r_cg_macrodriver.h
r_cg_cgc.h
r_cg_port.h
r_cg_serial.h
r_cg_timer.h
r_cg_userdefine.h
Declaration
void CSI00_Status_check (void)
Explanation
Checks the status of the slave.
Sets the status check flag, g_status_confirmation_flag, to 1 when the slave status
check ends normally.
Arguments
• None
Return value
• None
Remarks
None
[Function Name] CSI00_Send_Receive
Synopsis
CSI transmission/reception
Header
r_cg_macrodriver.h
r_cg_cgc.h
r_cg_port.h
r_cg_serial.h
r_cg_timer.h
r_cg_userdefine.h
Declaration
void CSI00_Send_Receive (void)
Explanation
Performs the master transmission/reception processing.
Arguments
• None
Return value
• None
Remarks
None
