RX66T CPU Card User’s Manual
R12UZ0029EJ0120 Page
11
of 25
2022.2.21
5. Functions
5.1 Power Supply
The product does not have a dedicated power supply connector. When connected to the INV-BRD it draws power via
the connector. When not connected to the INV-BRD, it can draw power via the Emulator connector. The product is not
allowed to draw power via the Emulator connector when it is connected to the INV-BRD.
5.2 Connecting the Emulator
The E1/E2 Lite on-chip debugging emulator from Renesas Electronics is used to write software (program) to the flash
memory of the RX66T. Software will be downloaded into the product via E1 or E2 Lite. It is also necessary to make the
settings shown in Table 5.1 in the integrated development environment or in the Renesas flash programmer to enable
the emulator to supply power to the product. Table 5.2 lists the pin assignments of the Emulator connector.
Table 5.1 E1, E2 Lite Power Supply Settings
Connection to INV-BRD
Power Supply Setting of E1, E2 Emulator
Connected
Power supply is not allowed*
1
Not connected
5.0V or 3.3V power supply
Note 1. When connected to the INV-BRD, the product must draw power from the INV-BRD.
Table 5.2 Pin Assignments of Emulator Connector (CN7)
Pin No.
Pin Function
RX66T
Connection Pins
Pin No.
Pin Function
RX66T
Connection Pins
1
TCK/FINEC
TCK
2
GND
VSS
3
TRST#
TRST#
4
EMLE
EMLE
5
TXD1/TDO
TXD1
6
NC
-
7
MD/FINED
MD/FINED
8
VCC
VCC
9
TMS
TMS
10
UB
UB
11
TDI/RXD1
RXD1
12
GND
VSS
13
RESET#
RES#
14
GND
VSS
Note: See a supplement to the E1/E20/E2 emulator, E2 emulator Lite user’s manual.
