Technical Data
Nominal Voltage 230 V 120 V 100 V
Permissible mains voltage: 220 - 240 V 120 V 100 V
Mains frequency: 50 / 60 Hz
Power consumption: 9 W
Maximum connection pressure: 6 - 8 bar [87- 116 psi]
Working pressure: 1 - 6 bar [14.5 - 87 psi]
Dimensions (Width x Height x Depth): 350 x 275 x 400 mm [13.8 x 10.8 x 15.7 inch]
Weight, approx.:
- 1 tank version:
- 2 tank version:
4.4 kg [9.7 lbs]
5.5 kg [12.1 lbs]
Ø Compressed air hose:
- interior:
- exterior:
4 mm [157 mil]
6 mm [236 mil]
Ø Size of pipe union for external extraction unit:
- interior:
- exterior:
35 mm [1.38 inch]
40 mm [1.57 inch]
Blasting chamber volume: 10 l [2.64 US gal]
Tank capacity, each: 1000 ml [34 oz]
