EN
Standard delivery
1 Sandblasting unit Basic eco
1 Foot switch
1 Connection set
1 Dosing nipple tool
1 Quick Start Guide
Delivery format
2949 1XXX, 2949 3XXX 1 tank version
2949 2XXX, 2949 4XXX 2 tank version
Installation
Unpacking
⇒ Check to ensure all delivery parts are complete (compare “Included in Delivery”).
Setting up
⇒ Place the unit on a level and stable base.
Connect foot switch
When inserting the tubes you will notice a slight resistance which must be overcome.
2 Tank version:
⇒ Push the tube marked „A“ as far as it will go into the tube connection point „A“ (13).
⇒ Push the tube marked „B“ as far as it will go into the tube connection point „B“ (19).
1 Tank version:
⇒ Push the tube marked „A“ as far as it will go into the tube connection point „A“ (13).
⇒ Push the tube marked „B“ as far as it will go into the tube connection point „B“ (22)
(on sandblasting tank).
Compressed air connection
⇒ Push the compressed air tube (11) onto the tube connection point (14) as far as it will go. In doing so
there will be a slight resistance to overcome.
⇒ Select the relevant hose connection piece from the enclosed attachment set and t it onto the end of
the tube.
⇒ Attach to the compressed air network.
Electrical connection
⇒ Insert the power plug into the building installed wall socket.
Connect to extraction unit
⇒ Connect the suction tube from the extraction unit to the suction pipe (18).
For suction devices with automatic activation:
⇒ connect the mains plug from the sandblasting unit into the user socket on the suction device.
Filling the sandblasting tanks
Attention: Never press the foot switch during lling.
⇒ Add abrasive up to the maximum ll level (the point where the tank jacket thickens just below the
thread).
⇒ Reinstall the tank lid (5).
- 3 -
