1-6
LED check
Switch on method
Optical on
or
Shank on
or
Spin on
Switch off method (omitted for shank on)
Optical off or
Spin off
or
Short time out
12 s
or
Medium time out
33 s
or
Long time out
134 s
Reviewing the probes settings
X
> 5 s
Key to symbols
LED short flash
LED long flash
1
2
3
