Description Parameter
Standby Power Consumption 0.04W
Operating Power Consumption 0.05W
Communication Range
Serial Baud Rate
Communication Protocol RS232
Port Type RJ12
Cable Length 5.00m (16.4ft)
Dimensions
67.3 X 35 X 14mm
2.65 X 1.38 X 0.55in
Installation Dimensions
Weight 130g(4.58oz)
Operation Temperature
Protection Grade IP54
82ft25m
Fixed Baud Rate 9600bps
67.3 φ3.5mm2.66 φ 0.14in
BT-1
-20~85℃(-4°F to 185°F
Model
Technical Specifications
14
