Step 8. Connect the Battery to Other Devices
Please use circuit breakers, fuses, or disconnects appropriately sized by a certified electrician, licensed
installers, or regional code authorities to protect all electrical equipment.
█
For a Single Battery
Battery Fuse
Inverter DC-DC Charger
DC Distribution
Panel
Charge Controller
█
For Batteries in Parallel
Battery Fuse
Inverter DC-DC Charger
DC Distribution
Panel
Charge Controller
█
For Batteries in Series
Battery Fuse
Inverter DC-DC Charger
DC Distribution
Panel
Charge Controller
