Renu Electronics FlexiPanels Basic FP2070TN-E - Page 19

FlexiPanels
®
Basic HMI
© Renu Electronics Pvt. Ltd.
Page 19 of 24
FPEM-0404P-A0402U
FPEM-0806P-A0402U
Power Supply
Powered from FP2 base Modules
DC Inputs
4 (Sinking & Sourcing)
8 (Sinking & Sourcing)
High Speed
Inputs
2, 32 Bit, 200kHz
2, 32 Bit, 200kHz
DC Outputs
4 PNP
6 PNP
High Speed
Pulse Outputs
2, Up-to 200kHz each
2, Up-to 200kHz each
Analog Inputs
Universal Type 4 Inputs, Voltage
Inputs [16Bit]:
0 to 10VDC, 0 to 5VDC
0 to 50mV, 0 to 100mV, RTD-
PT100, Thermocouple J & K type
Linear Type 2 Inputs, Voltage
Inputs [16 bit]:
0 to 10VDC, 0 to 5VDC
0 to 50mV, 0 to 100mV, RTD-
PT100, Thermocouple J & K type
Current Inputs:
0 to 20mA & 4 to 20mA
Current Inputs:
0 to 20mA & 4 to 20mA
Analog Outputs
2 Voltage/Current Output [12 Bit]:
Current: 0 to 20mA & 4 to 20mA
Voltage: 0 to 5VDC & 0 to 10VDC
2 Voltage/Current Output [12 Bit]:
Current: 0 to 20mA & 4 to 20mA
Voltage: 0 to 5VDC & 0 to 10VDC
Isolation
Digital: Isolated from 24VDC power
Analog: Non-Isolated from 24VDC power and Communication, USB
ground
Operating
Temperature
0°C to 50°C (While using FPEM Modules with FP2 Base models)
Storage
Temperature
-20°C to 85°C
Humidity
10 to 95% non-condensing
Approvals
CE, UL Class I Div 2
Dimensions
(mm)
48W x 108H x 41D
