Reolink Argus PT Quick Start Guide

English English3 4
OFF
ON
POWER
RST
MicroSD
OFF
ON
POWER
RST
MicroSD
OFF
ON
POWER
RST
MicroSD
Set up the CameraCamera Introduction
Set up the Camera Using a Smartphone
Step 1 Scan to download the Reolink App from the App Store or Google Play store.
Step 2 Turn on the power switch to power on the camera.
Dierent states of the status LED:
Red Light: WiFi connection failed Blinking: Standby status
Blue Light: WiFi connection succeeded On: Working status
OFF
ON
POWER
POWER
OFF
ON
POWER
Lens
Power Switch
IRLEDs
Antenna
Spotlight
Charging Port
Daylight Sensor
Battery Status LED
Built-in PIR Sensor
Built-in Mic
StatusLED
Speaker
Reset Hole
Micro SD Card Slot
* Press for more than ve seconds to
restore the device to default settings.
* Rotate the camera’s lens to nd the
reset hole and the SD card slot.
1
11
2
12
3
13
4
14
5
6
7
8
9
10
4
8
10
9
3
2
1
12
11
5 7
13
14
6

Reolink Argus PT Specifications

General

Type	IP security camera
Antenna type	External
Remote viewing	Yes
Antennas quantity	1
Placement supported	Indoor
Connectivity technology	Wireless
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Sensor type	CMOS
Digital zoom	6 x
Total megapixels	- MP
Maximum resolution	- pixels
Supported video modes	1080p
Video compression formats	H.264
Cables included	Micro-USB
Pan range	0 - 355 °
Tilt angle range	0 - 140 °
Minimum illumination	- lx
Night vision distance	10 m
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Alert notification type	E-mail
Motion sensor technology	Passive infrared (PIR) sensor
DC output current	2 A
DC output voltage	5
Power source type	Battery, DC
Operating temperature (T-T)	-10 - 55 °C
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
International Protection (IP) code	IP65

Weight and Dimensions

Height	112 mm
Weight	470 g
Diameter	98 mm
