Reolink Argus PT User Manual

Reolink Wireless Battery-powered Camera
9
Argus Eco
Note:
There is no skin and wall mount for Argus Eco, and there is just one mounting
template. Except for the above differences, others are the same as Argus 2.
Argus PT
Note:
Except for the above parts, the surveillance sticker, quick start guide, reset needle
and USB cable are the same as others, but just one pack of screw in this box.
Install a Rechargeable Battery
Argus PT*1
Mounting Template*1
Bracket*1
Strap*1
Slide the battery downward
and lock it firmly.
Check the button status to see
if the battery is installed
correctly.
Argus Eco*1

Reolink Argus PT Specifications

General

Type	IP security camera
Antenna type	External
Remote viewing	Yes
Antennas quantity	1
Placement supported	Indoor
Connectivity technology	Wireless
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Sensor type	CMOS
Digital zoom	6 x
Total megapixels	- MP
Maximum resolution	- pixels
Supported video modes	1080p
Video compression formats	H.264
Cables included	Micro-USB
Pan range	0 - 355 °
Tilt angle range	0 - 140 °
Minimum illumination	- lx
Night vision distance	10 m
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Alert notification type	E-mail
Motion sensor technology	Passive infrared (PIR) sensor
DC output current	2 A
DC output voltage	5
Power source type	Battery, DC
Operating temperature (T-T)	-10 - 55 °C
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
International Protection (IP) code	IP65

Weight and Dimensions

Height	112 mm
Weight	470 g
Diameter	98 mm
