Reolink RLC-510A Operational Instruction

Stien the adjustment knob to
lock the camera.
Drill holes in accordance with the
mounting hole template.
NOTE: There are two dierent types of mounts for bullet cameras.
Please check out the mount included in the package and follow the
corresponding instruction to install the camera properly.
NOTE: Use the drywall anchors
included in the package if needed.
NOTE: Run the cable through the
cable notch on the mount base.
Install the mount base with the
mounting screws included in
the package.
To get the best field of view,
loosen the adjustment knob
on security mount and turn
the camera.
Install the Camera
10English9 English
1
2
3
4

Reolink RLC-510A Specifications

General

Form factor	Bullet
Weatherproof	Yes
Mounting type	Ceiling/wall
Product color	White
Housing material	Aluminum
International Protection (IP) code	IP66
Sensor type	CMOS
Number of sensors	-
Optical sensor size	1/2.7 \
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Number of lenses	1
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Number of illumination LEDs	18
Total megapixels	5 MP
Maximum resolution	2560 x 1920 pixels
Video formats supported	H.264
Minimum illumination	- lx
DC output current	1 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (typical)	12 W
Wi-Fi	No
Number of users	20 user(s)
Networking standards	IEEE 802.3af
Ethernet interface type	10 Gigabit Ethernet, 100 Gigabit Ethernet
Supported network protocols	HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Mobile operating systems supported	Android, iOS

Weight and Dimensions

Depth	186 mm
Height	67 mm
Weight	425 g
