Introduce the NVR
NOTE: The actual appearance and components may vary with dierent products.
Introduce the Cameras
Built-in Mic
Lens
Infrared Lights
Daylight Sensor
Power Port(Optional)
Network Cable
Waterproof Lid
Mount
Reset Button
* Press for about 10 seconds to restore factory settings.
USB Port
Power LED
HDD LED
Control Panel
USB Port
Power Switch
Audio Out
Power Input
HDMI Port
VGA Port
LAN Port
PoE Interface
