Reolink RLN16-410 Operational Instruction

AUDIO
OUT
USB HDMI VGA LAN 2
1
4
3
6
5
8
7
10
9
12
11
14
13
16
15
ON
OFF
DC 52V
IN
PWR HDD
ALL
MENU SELECT
12Deutsch
11 Deutsch
NVR-Einführung
USB-Port
Strom-LED
Festplatte-LED
Bedienfeld
USB-Port
Ein-/Ausschalter
Audio-Ausgang
Stromeingang
HDMI-Port
VGA-Port
Netzwerk
PoE-Ports
HINWEIS: Das Aussehen und der Lieferumfang der Kamera können je nach dem Produktmodell
variieren.
Lieferumfang
HDMI-Kabel
x1
NVR Power
Netzadapter
x1
USB-Maus
x1
NVR
x1
Netzwerkkabel
1 Meter
x1
Kurzanleitung
x1

Reolink RLN16-410 Specifications

General

Number of users	20 user(s)
Maximum resolution	1920 x 1080 pixels
Video input channels	16 channels
Supported resolutions	1024x768, 1280x720, 1280x800, 1280x1024, 1440x900, 1920x1080
Operating system installed	Embedded LINUX
Product color	Black
eSATA ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN data rates	1000 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	17
Supported network protocols	HTTP, HTTPS, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Total installed storage capacity	3000 GB
Mobile operating systems supported	Android, iOS
Output current	2.5 A
Output voltage	48 V
AC input voltage	100-240 V
Power consumption (typical)	20 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	HDMI, LAN (RJ-45)
Wi-Fi	No

Weight and Dimensions

Depth	260 mm
Width	330 mm
Height	45 mm
Weight	3000 g
