Solar / Basic settings
Ext. HX
Designation Factory setting
Scheme 001/011 002/012 003/013 004/014
Relay 3 3 3 3
Min. speed 30% 30% 30% 30%
Store 1 1 1 1
Sensor ext. HX 3 3 3 3
Target temperature No No No No
ΔTo n 5 5 5 5
ΔToff 3 3 3 3
Overrun 0 0 0 0
Function activated activated activated activated
Arrangement / Optional function
Heat exchange
Designation Factory setting
Scheme 001/011 002/012 003/013 004/014
Relay 4 4 4 4
Sen. Source 5 5 5 5
Sen. Sink 7 7 7 7
ΔTon 3 3 3 3
ΔToff 1 1 1 1
ΔTset 10 K 10 K 10 K 10 K
Min. speed 100 100 100 100
Tmax 95 95 95 95
Tmin 55 55 55 55
Timer - - - -
Function activated activated activated activated
HQM
HQM1
Designation Factory setting
Scheme 011 012 013 014
Flow sen. S3 S3 S3 S3
Return sen. Gd1 Gd1 Gd1 Gd1
Sen. flow r. Yes Ye s Ye s Ye s
Sen. flow r. Gd1 Gd1 Gd1 Gd1
Fluid type Propyl. Propyl. Propyl. Propyl.
Ratio - - - -
HQM
HQM2
Designation Factory setting
Scheme 011 012 013 014
Flow sen. S5 S5 S5 S5
Return sen. Gd2 Gd2 Gd2 Gd2
Sen. flow r. Yes Ye s Ye s Ye s
Sen. flow r. Gd2 Gd2 Gd2 Gd2
Fluid type - - - -
