43
31. PROBE: 15 pin Cannon connector for hookup of the middle ear analyzer probe
32. PRESSURE: junction connector for connection of the middle ear analyzer probe
pressure tube.
33. PAT. RESP: 6.35 mm stereo jack input for connection of the patient response
pushbutton used during audiometry testing
34. FOOT SWITCH: no longer in use
35. SD CARD: slot for the external SD card; supplied with the device, providing a broad
range of multilanguage speech recordings used for speech audiometry testing
36. : USB host port for hook-up of a USB keyboard and/or an external USB data
storage pen drive
37. : USB slave port for PC communication and data transfer
38. ON-OFF switch: on-o switch with fuse holders and mains power supply cable
connection
39. Operator goose-neck microphone connection: area provided for attaching an
optional operator microphone
