Connecting/Disconnecting direct audio boot
or integrated FM
Connecting audio boot and integrated FM
1. Align the tip of the audio boot or integrated FM boot with the
groove just above the battery compartment and below the
model number.
2. Once in place, move the boot in the direction of the battery
compartment.
3. Gently click the boot onto the hearing instrument.
Disconnecting audio boot and integrated FM
4. Press and hold the button on the front side of the audio boot.
For an FM boot, slide the latch downward with your finger nail.
5. Gently remove the boot from the hearing instrument.
Direct audio Integrated FM
