RESQTEC FX Series - Table of Contents

USER MANUAL FX-SERIES & WX-SERIES FRONTLINERS
RESQTEC Manual FRONTLINER FX-Series (DM003K14)2
1. INTRODUCTION: SAFETY FIRST 03
1.1. Safety messages 03
1.2. General safety information 03
1.3. Safety information 04
1.4. Product identication 04
1.5. Applicable types 05
2. PRODUCT SUMMARY 06
2.1. Introduction 06
2.2. Product description 06
2.3. Component identication 06
3. PRODUCT RANGE 09
3.1. Products & Accessories 09
4. GENERAL OPERATING INSTRUCTIONS 11
4.1. Initial use 11
4.2. Preparation before use 11
4.3. Operation 12
4.4. Optimized 350 bar 12
4.5. Quick action couplers 13
4.6. Connecting the Resqtec NEO1 coupler 13
4.7. Disconnecting the Resqtec NEO1 coupler 14
4.8. Connecting the Resqtec STD coupler 15
4.9. Disconnecting the Resqtec STD coupler 15
4.10. Using the pressure release 16
4.11. Operating the product 17
4.12. Removing & placing the FX2 Spreading Jaws 18
4.13. Attaching & Detaching Pulling Jaws & Chains and Shackles 19
4.13.1 FX2 19
4.13.2 Fx4-Fj / FX6-Fj / G4WX 20
5. SPECIFICATIONS 23
5.1. Technical specications 23
5.1.1 SI-system data 23
5.1.2 Imperial system data 25
5.2. Cutting Capabilities 27
5.3. Technical drawings 27
5.3.1 Si-System Data 27
5.3.2 Imperial System Data 29
6. MAINTENANCE & STORAGE 30
6.1. Maintenance after use 30
6.2. Regular maintenance 32
6.3. Annual maintenance 33
6.4. Recommended storage 33
6.5. Decommissioning & recycling 33
7. WARNINGS & LIMITATIONS 34
7.1. General instruction 34
7.2. Twisting of blades 34
8. TROUBLESHOOTING 35
9. WARRANTY 36
10. DISCLOSURE 37
11. CONTACT 38
