Using the PLT
®
Solas
Aim over the target while making sure that
the PLT
®
Solas Launching Unit is supported
against something solid by using the Damper
Pad on the PLT
®
Solas Air Cylinder Cover.
For maximum distance hold elevation between 25° to 35°.
Push and hold the safety knob and aim over the target.
Pull the trigger with a rm and rapid movement.
The projectile will now be launched.
ProjectileTrigger
25–35˚
Safety knob
Closing valve
Damper pad
Pressure chamber
8 9
