Page 12 of 13
UPPER BUNK MATTRESS DIAGRAM
MATTRESS
SLAT ROLL
GUARDRAIL
SIDE RAIL
12''
MAXIMUM
THICKNESS
5'' MINIMUM DISTANCE
FROM TOP OF MATTRESS
TO TOP OF GUARDRAIL
BEDDING SPECIFICATION:
The following size mattress and Foundation are specified for use with this Bunkbed:
MATTRESS:37-1/2'' to 38-1/2'' X74'' to 75''x11''H max
SLAT ROLL (CONSISTING OF 14 SLATS)-: 39-1/2'' W X2-1/2'' L X1''H
**Note:MATTRESS AND SLAT ROLL MUST NOT EXCEED 12'' TOTAL THICKNESS
Be sure to adhere to these BEDDING SPECIFICATIONS,In order to avoid the possibility of
falling or entrapment, THESE SPECIFICATIONS MUST BE STRICTLY ADHERED TO!
