Twin Bed Assembly Instruction:
1.Attach the side rails (C) to the tall end(headboard) (A) & short end (footboard) (B) using thread
rods(H),curved slotted washers(I) and wrench(J) that is provided(Refer to Section "A").Place
thread rods in the holes on the tall & short bed post . Align the side rails with the holes and
fasten tightly with curved slotted washers using the wrench provided.
JJ
HH
II
AA
CC
CC
DD
BB
QQ
Side RailSide Rail
Section "A"Section "A"
Tall End PostTall End Post
Section "B"Section "B"
OO
Sect o "
i n B"Sect o "
i n B"
c ASe tion " "c ASe tion " "
SlatSlat
QQ
Philip ScrewdriverPhilip Screwdriver
JJ
HH
II
AA
CC
CC
DD
BB
QQ
Side RailSide Rail
Section "A"Section "A"
Tall End PostTall End Post
Section "B"Section "B"
OO
Sect on "B"
iSect on "B"
i
Sec on "A
ti "Sec on "A
ti "
SlatSlat
QQ
Philip ScrewdriverPhilip Screwdriver
2.Lay the slat roll (D) in between the side rails (C) and use slat roll screws #8x1 1/4" (O) to
fasten two end slats to side rails with a screwdriver (Refer to Section "B").
3.Put the wooden caps (Q) on the tall end (headboard).
Bunk bed can convert to two twin beds, assemble beds following below instructions:
