5 6
ICON DESCRIPTION
INT Select International Channel.
CAN Select Canadian Channel.
Appear while channel is busy.
Flash while in Scan Channel.
Appear when TAG Channel is selected.
CALL Appear when Call Channel is selected.
Battery indicator.
Indicate piecewise while charging.
Flash while full charging.
SCAN Flash while scanning.
Appear while key locked.
DUP Appear while a duplex channel is selected.
DUAL Appear while dual watch.
TRI Appear while tri-watch.
ICON DESCRIPTION
Indicate the operating channel number.
Indicate the selected condition in set mode.
Indicate assistant channel.
Appear while setting volume.
Appear while setting squelch.
Appear while setting mode.
Appear while weather alarm.
WX Appear while weather channel is selected.
BASIC OPERATION
Power ON/OFF
1. Hold [ ] for 2 seconds to power on.
2. Hold [
]·½·¿Ä¼ÅÈʸÉ»¹ÅĺÊÅÆÅÍ»ÈÅŮƔ
Adjust the Volume Level
The volume level can be adjusted through [VOL/SQL] and
[
Y
]/[
Z
].
1. Press [VOL/SQL] and then press [
Y
]/[
Z
] to adjust the
volume level.
The “VOLƢطɾ»ÉƔ
There are 31 volume levels. OF means the volume is
ÊËÈÄ»ºÅŮƔ
When no operation is performed within 5 seconds, the
radio returns to normal mode.
2. Press [VOL/SQL] again to exit the volume adjustment
mode.
Adjust the Squelch Level
The squelch level can be adjusted through [VOL/SQL] and
[
Y
]/[
Z
]. Set the proper squelch level to have better receive
É¿½Ä·Â·Äº»Ů»¹ÊË·Âɹ·ÄƔ
1. Press [VOL/SQL] for twice and then press [
Y
]/[
Z
]to ad-
just squelch level.
• “SQLƢطɾ»ÉƔ
The radio has 11 squelch levels. OP is completely open.
10 is maximum squelch.
When no operation is performed within 5 seconds, the
radio returns to the normal mode.
2. Press [VOL/SQL] again to exit squelch level adjustment
mode.
Transmit and Receive
D
Transmit
1. Press [Hi/Lo] to select transmit power.
• “LOW” appears when low power is selected.
Select low power for short distance communication
while high power for long distance communication.
• Some channels are for low power transmit only.
2. Press and hold [PTT] to transmit. Then speak to micro-
phone.
• “
appears.
• Channel 70 cannot be used for normal transmission.
3. Release [PTT] to receive.
NOTE:
• Transmitting without antenna will damage the radio.
To forbid the long time continuing transmit, please turn on
TOT Function through PC programming software.
• Hold the microphone 5-10cm from your mouth while talking.
D
Receive
1. Enter volume adjustment mode. Press [
Y
] or [
Z
] to ad-
just.
