RETRO 176 - 2.3 Input Connection; 2.4 Output Connection

2.2.3 Line Cord
You can use a compatible IEC power cable for 100-120 Volts or 200-240 Volts per your
country’s specification.
USA Europe Australia
2.3 Input Connection
Audio Input is a standard female XLR connector. It is transformer balanced and floating,
meaning there is no path to ground from pin 2 and 3. Unbalanced sources connect the
center conductor to pin 2 and the shield to pin 3.
2.4 Output Connection
Audio Output is a standard Male XLR connector. It is transformer balanced and floating,
meaning there is no path to ground from pin 2 and 3. Unbalanced loads connect the
center conductor to pin 2 and the shield to pin 3.
