23 24
VII. Power wire of the speed sensor is
connected with the controller
1. Blue (signal)
2. Red (+5V)
3. Black (ground)
V.Display wire is connected with the
display
1. Yellow (displayer signal ZF)
2. Green (displayer signal IL)
3. Blue (lock wire)
4. Black (-)
5. Red (+)
VI. Throttle
1. Purple (+5V)
2. Grey (signal)
3. Black (ground)
12. Main Technical Specication Sheet
Please nd model name of your bike below:
Here is some of the general technical data for this electric bike:
Please nd the crossed technical data regarding the bike motor below:
Please nd the crossed technical data battery and charger below:
Maximum Speed with Electric Assistance:
Motor Type:
Battery Type:
Model
Maximum Output Power:
Brushless with Starry Gears_with Hall
Lithium
Remark (for reference)
Distance per Full Charge:
Maximum Riding Noise:
Voltage:
Rated Voltage:
<60db
13Ah
Over Current Protection Value:
Rated Power:
Capacity:
Under Voltage Protection Value:
32km/h (20mph)
I. Motor wire is connected with motor
1. Green (motor HA)
2. Yellow (motor HB)
3. Blue (motor HC)
4. Red (+5V)
5. Yellow (motor H2)
6. Green (motor H3)
7. Blue (motor H1)
8. Black (ground)
9. White (wheel speed signal)
IV.
Brake lever wire is connected with
the brake lever
1. White (brake signal)
2. Black (5V)
KOA REV
II. Power wire is connected with the
power
1. Red (48V)
2. Black (ground)
III.
1. Yellow (displayer signal 2F)
2. Green (displayer signal 2L)
3. Blue (lock wire)
4. Black (-)
5. Red (+)
6. White (brake signal)
7. Purple (5V)
8. Grey (throttle)
48V/750W
48V: 50~60km (total loading ≤75kgs)
21 ± 1A
40 ± 0.5V
750W
750W
48V
48V
